Dormer Machine taps DIN 2184-1C EP31 UNF 3/4 ″x16 HSS-E-PM steam tempered 2.5XD 2B

was CHF163.41
Ratings
Delivered between Thu, 26.6. and Sat, 28.6.
More than 10 items in stock at supplier

Product details

Dormer UNF machine tap, straight fluted with peel cut HSS-E-PM DIN 2184-1 Other technical features: - Cutting direction: Right - Gg/1″: 16 - Form: C - Design: Gate 2 - 3 threads, form C - Thread length: 30mm - Shank Ø: 14mm

zero.

Key specifications

tap type
Taps
thread type
UNF10-32
Set
Singles
Item number
22161033

General information

Manufacturer
Dormer
Category
Threading taps + Threading dies
Manufacturer no.
EP313/4
Release date
13.9.2022

Tap Properties

tap type
Taps
thread type
UNF10-32
Internal diameter
17.50 mm
Outside diameter
19.05 mm
gradient
0 mm
DIN standard
DIN 2184-1
Set
Singles
Direction of rotation
Right + Left

Origin

Country of origin
India

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
4 inchx16 HSS-E-PM steam tempered 2.5XD 2B, Machine tap DIN 2184-1C EP31 UNF 3

Product dimensions

Length
125 mm
Diameter
101.60 mm
