Product details

Busch-Jaeger Bus Coupling Unit 6120/12-101

Manufacturer: Busch-Jaeger
Designation: Bus coupling unit, flush-mounted
Voltage: 24V
Current: 5mA
Type: 6120/12-101
Bus System KNX: Yes
Bus System Radio Bus: No
Bus System LON: No
Bus System Powernet: No
Other Bus Systems: Other
Mounting Type: Flush-mounted
Width in Division Units: 1
Number of Connections Sensor/Actuator: 1
Min. Depth of Device Box: 33 mm

This bus coupling unit is compatible with the Busch-priOn basic frame 1-gang 6346/10-10x and the control elements 6122/0x-xxx, 6124/0x-xxx, 6125/0x-xxx, 6126/0x-xxx, 6127/0x-xxx, 6128/0x-xxx, 6129/0x-xxx. The bus connection is made via the included bus terminal. For programmable functions, please refer to the current application description, which is available for download.

EAN: 4011395135471.

Key specifications

Protection type (IP code)
IP20
Length
30 mm
Width
45 mm
Height
50 mm

General information

Item number
20025267
Manufacturer
Busch-Jaeger
Category
Wiring closet technology
Manufacturer No.
2CKA006120A0074
Release date
16.3.2022

Colour

Colour
Grey
Exact colour description
Metallic

Material

Material group
Plastic

Distribution cabinet technology Features

Area of use
Inside
Nominal current
0.02 A
Protection type (IP code)
IP20
Nominal voltage
24 V
Divisions
1x

Smart home features

Communication standard
KNX
Transmission type
Wired

Origin

Country of origin
Germany

Voluntary climate contribution

CO₂ emissions
29.26 kg
Climate contribution
CHF 0.70

Scope of delivery

Items per sales unit
1 pcs.

Product dimensions

Length
30 mm
Width
45 mm
Height
50 mm
Depth
23 mm

Package dimensions

Length
12 cm
Width
4 cm
Height
10 cm
Weight
255 g
