Amf Horizontal clamping device

19Ratings
BrandMore from Amf
Delivered between Tue, 2.6. and Wed, 3.6.
Only 1 piece in stock at supplier
Free shipping starting at 50.–

Product details

Horizontal tensioner with horizontal foot type 6830 NI

  • Rivet made of stainless steel
  • From size 2, case-hardened bearing bushings
  • Lubricated bearing points
  • Open holding arm
  • Ergonomic handle made of red, oil-resistant plastic
  • Non-rusting polished steel
  • Suitable for the food industry

Delivery: Complete with non-rusting pressure screw.

Measurement table:
A 5.0 mm
B 42.0 mm
C 13.0-14.5 mm
D 5.2 mm
D1 - mm
E 18.7 mm
F 8.0 mm
H 19.0 mm
H1 30.0 mm
H2 49.0 mm
HW min. -3.0 mm
HW max. 2.5 mm
I 10.0 mm
K 5.5 mm
L - mm
L1 120 mm
M 18.0-21.5 mm
M1 - mm
N 34.0 mm
P 34.0 mm

  • 90°

* The opening angle can be adjusted by pressing in a stop pin.

Technical data
Total length: 130 mm
Size: 1
Clamping height: 30 mm
Clamping force F1: 0.8 kN
Clamping force F2: 1.1 kN
Pressure screw: M5 x 30
Weight: 120 g

Article number: DVE4020772095161
Shop number: DVE4020772095161
EAN: 4020772095161.

Key specifications

tension
800 kg
Length
120 mm

General information

Item number
10005186
Manufacturer
Amf
Category
Vices + Clamps
Manufacturer No.
95166
Release date
25.10.2018
Sales rank in Category Vices + Clamps
332 of 6381

Colour

Colour
Red
Exact colour description
Red

Material

Material group
Metal
Material
Stainless steel

C-Clamp Features

jib length
130 mm
tension
800 kg

Origin

Country of origin
Germany

Voluntary climate contribution

CO₂ emissions
0.69 kg
Climate contribution
CHF 0.11

Product dimensions

Length
120 mm
Width
42 mm
Height
30 mm
Weight
120 g

Package dimensions

Length
12.70 cm
Width
7.50 cm
Height
3.10 cm
Weight
114 g
