Shimano Nexus Di2

Disc brake Center lock
Ratings
Delivered between Thu, 21.8. and Mon, 25.8.
8 pieces in stock at supplier
free shipping

Product details

The NEXUS Di2 5-speed system offers function, quality, and design at a high level. In functional terms, the achieved progress lies, among other things, in the integration of Shimano's unique shift servo technology, which allows switching with the least effort.

Details:

  • Gear ratio: 263%
  • Axle length: 187 mm
  • Type: gear hub
  • Bolt circle diameter: 92.6 mm
  • Application: e-bike
  • Flange diameter: 105.2 mm
  • Type: rear wheel
  • Flange spacing: 57.3 mm
  • Rear hub
  • Gear hub compatibility: gear hub
  • Brake type: disc brake Center Lock
  • Material: aluminum
  • Diameter axle: 10 mm
  • Installation width: 135 mm.

Key specifications

Material
Aluminium
Bike area of use
Electric bike
Axle diameter
10 mm
Installation width
135 mm
Item number
12770982

General information

Manufacturer
Shimano
Category
Hubs + Freewheels
Manufacturer no.
ISGC70505DBL
Release date
20.2.2020

Colour

Colour
Black
Exact colour description
Black

Material

Material group
Metal
Material
Aluminium

Wheel properties

Bike area of use
Electric bike

Hub + freewheel Features

Hub type
Gear hub
Ability brake type
Disc brake Center lock
Axis standard
Screw axis
Number of holes
32 x
Axle diameter
10 mm
Installation width
135 mm
Cassette compatibility
5-speed

Origin

Country of origin
France

Voluntary climate contribution

CO₂-Emission
Climate contribution

Package dimensions

Length
20 cm
Width
20 cm
Height
20 cm
Weight
1.69 kg

30-day right of return if unopened
24 Months Warranty (Bring-in)
