Best selling Thermal pads

Here's a ranking of the best products in this category. To give you a quick overview, we've also added some key information about the products.

1. Iceberg Thermal DRIFTIce Thermal Pad.

DRIFTIce by Iceberg Thermal is easy to apply, precise, and ensures even contact when filling air gaps. The thermal conductivity of this thermal pad is 13 W/mK. Iceberg Thermal guarantees that you will be satisfied with the heat transfer of DRIFTIce. DRIFTIce can be used as a thermal gap filler for your VGA cards, RAM, and notebook PC components. The thermal pads are available in various sizes and thicknesses. You choose the thickness according to your needs. You are in control.

Iceberg Thermal DRIFTIce Thermal Pad. (1 mm, 13 W/m K)
Thermal pads
CHF9.50

Iceberg Thermal DRIFTIce Thermal Pad.

1 mm, 13 W/m K

2. Thermal Grizzly KryoSheet

Thermal Grizzly presents KryoSheet, a new product that is part of the company's advertised high-performance cooling solutions. The graphene thermal pads from the Thermal Grizzly KryoSheet series can serve as an excellent alternative to high-end thermal pastes. Similar to the Carbonaut pads, they feature a flexible surface with very high thermal conductivity.

3. Iceberg Thermal DRIFTIce Thermal Pad.

Iceberg Thermal is a manufacturer dedicated to creating the best possible solutions in the PC cooling industry. Most of the engineers on the team have over 15 years of experience and can apply this expertise at every stage of production, from the initial design to the factory floor and into the hands of the customer.

Iceberg Thermal DRIFTIce Thermal Pad. (0.50 mm, 13 W/m K)
Thermal pads
CHF7.50

Iceberg Thermal DRIFTIce Thermal Pad.

0.50 mm, 13 W/m K

4. Thermal Grizzly PhaseSheet PTM - 50x40mm

The phase-change material on which the PhaseSheet PTM is based is solid at room temperature. The material only begins to liquefy at temperatures above 45 degrees Celsius. A high contact pressure of around 300-400N is required for optimum distribution of the liquid PhaseSheet PTM and thus the lowest possible layer thickness. PhaseSheet PTM has a very low viscosity in its liquid state and contracts again when it changes to a solid material. This minimises the pump-out effect. The pump-out effect is particularly pronounced when combining a copper cooler on a graphics chip because silicon and copper have different linear expansion when heated. The temperatures under load cause the heat spreader and the base plate to deform (concave or convex) and return to their original shape (straight) during cooling. As a result, the thermally conductive paste is slowly pressed out between the heatspreader and the base plate of the CPU cooler, for example. PhaseSheet PTM is more durable than traditional thermal pastes, but not as durable as KryoSheet, for example, which is virtually maintenance-free. The maximum thermal conductivity of PhaseSheet PTM develops and stabilises after around ten heat cycles above 60 degrees Celsius. Brief information Outstanding thermal conductivity Consistently high performance Very long service life Versatile in use Non-electrically conductive Easy to use Scope of delivery 1x PhaseSheet PTM.

Thermal Grizzly PhaseSheet PTM - 50x40mm (0.20 mm)
Thermal pads
CHF14.–

Thermal Grizzly PhaseSheet PTM - 50x40mm

0.20 mm

5. Thermal Grizzly Minus Pad 8 (100x100x2mm)

The easy to process and flexible minus pads consist of different components: They are based on a ceramic-silicone formula complex, nano-aluminum oxide. The pads thus always guarantee optimum heat transport.

Even the slightest contact pressure is sufficient for optimum fastening. All pads are environmentally friendly and RoHS compliant.

W/mK 8.0, temperature range -100°C / +200°C


Thermal Grizzly Minus Pad 8 (100x100x2mm) (2 mm, 8 W/m K)
Thermal pads
CHF30.70

Thermal Grizzly Minus Pad 8 (100x100x2mm)

2 mm, 8 W/m K

6. Arctic Thermal pad 0.5 mm

The Arctic Thermal Pad provides an efficient thermal interface between heat sinks and electronic devices when uneven surfaces, air gaps, and rough surface structures are present. The silicon-based material outperforms generic pads, is flexible and adaptable, and thus works even under low pressure. 145 x 145 mm (0.5).

Arctic Thermal pad 0.5 mm (0.50 mm, 6 W/m K)
Thermal pads
CHF9.70

Arctic Thermal pad 0.5 mm

0.50 mm, 6 W/m K

7. Thermal Grizzly Carbonaut thermal pad - 32 × 32 × 0.2 mm

Thermal Grizzly from Hamburg is a new German brand dedicated to combating high temperatures and poor heat transfer. The goal is to supply the overclocking community with high-performance thermal interface products, which remain a weak point. However, the product portfolio can also be used for better and quieter cooling of gaming PCs, workstations, mini-PCs, and many other applications. In addition to higher clock rates, better thermal interface products enable quieter cooling and a longer lifespan for the components being cooled.

To achieve these goals, Thermal Grizzly has closely collaborated with renowned extreme overclocker Roman "der8auer" Hartung during product development and testing, developed chemical compositions, and analyzed competitors. The product line is now expanded with an innovation in thermal pads: Thermal Grizzly's Carbonaut.


Thermal Grizzly Carbonaut thermal pad - 32 × 32 × 0.2 mm (0.20 mm, 62.50 W/m K)
Thermal pads
CHF13.90

Thermal Grizzly Carbonaut thermal pad - 32 × 32 × 0.2 mm

0.20 mm, 62.50 W/m K

8. Thermal Grizzly Carbonaut thermal pad - 38 × 38 × 0.2 mm

To achieve these goals, Thermal Grizzly has worked closely with and tested the well-known extreme overclocker Roman "der8auer" Hartung during product development, developing chemical compounds and analyzing competitors.

The features of the Thermal Grizzly Carbonaut thermal pad at a glance: Reusable, non-adhesive heat-conducting pad. Made of carbon-based polymer with nanoparticles. Extremely high thermal conductivity of 62.5 W/(m-K). 0.2 mm thick and 38 × 38 mm Intel CPUs for Socket 2066 and AMD CPUs for Socket AM4. Attention. Please observe the manufacturer's warnings before use. The Carbonaut is electrically conductive and is therefore not suitable for use on MOSFETS or voltage converters.


Thermal Grizzly Carbonaut thermal pad - 38 × 38 × 0.2 mm (0.20 mm, 62.50 W/m K)
Thermal pads
CHF15.90

Thermal Grizzly Carbonaut thermal pad - 38 × 38 × 0.2 mm

0.20 mm, 62.50 W/m K

9. Thermal Grizzly Minus Pad 8 - 120

Very efficient thermal pad with good thermal conductivity and a thickness of 3 mm. Dimensions are 120 × 20 mm.

Thermal Grizzly Minus Pad 8 - 120 (3 mm, 8 W/m K)
Thermal pads
−10%
CHF15.– was CHF16.70

Thermal Grizzly Minus Pad 8 - 120

3 mm, 8 W/m K

10. Gelid Solutions TP-GP04-R-B Thermal Paste Thermal Pads

The GP-Ultimate 120×20 is designed to provide a perfect thermal interface to transfer heat to heatsinks when installed on PCBs with height differences and uneven surfaces such as DRAM ICs, VRM ICs, power MOSFETs, NVRAM ICs, and other high-temperature SMD components. Thanks to its enhanced multilayer matrix, superior material composition, and the ultimate 15W/mK thermal conductivity, the GP-Ultimate 120×20 offers the best performance in its class.

The GP-Ultimate 120×20 is non-electrically conductive, non-corrosive, non-curing, non-toxic, and supports an extended operating temperature range of -60°C to 220°C. It features seamless application and has thermal pad dimensions of 120x20mm to best fit enlarged surfaces of RAM memory modules, GPU and CPU VRM circuits, M.2 Type SSDs, and other densely packed electronic devices.


Gelid Solutions TP-GP04-R-B Thermal Paste Thermal Pads (1 mm, 15 W/m K)
Thermal pads
−16%
CHF11.70 was CHF13.90

Gelid Solutions TP-GP04-R-B Thermal Paste Thermal Pads

1 mm, 15 W/m K
