Velleman Slide Switch 1P On-On

Technical data
Switching position:

• Left: On (Terminal connection: 2-1)
• Middle: -
• Right: On (Terminal connection: 2-3)

Contacts:

• 6A with 120Vac load resistance or 28Vdc
• 2A with 250Vac load resistance

Electrical life: 30,000 operations at full load
Contact resistance: Initially max. 10 mΩ
Insulation resistance: Min. 1,000 MΩ
Dielectric strength: 1,000 Vrms at sea level
Operating temperature: -30°C to +85°C

Materials:

• Housing: Diallylphthalate
• Slide: Nylon
• Housing: Stainless steel
• Contacts: Silver plated
• Center contact: Silver plated brass.
