Velleman Miniature Pcb Slide Switch 1P On-On 0.2"
Delivered between Fri, 6.6. and Tue, 17.6.
More than 10 items in stock at supplier
More than 10 items in stock at supplier
Product details
Technical data
Grid dimension: 5.08".
Switching position: left: On in the Miite: - right: on
left: A
at the Miite: -
on the right: A
Contacts: 6A with 120Vac load resistance or 28Vdc 2A with 250Vac load resistance
6A with load resistance of 120Vac or 28Vdc
2A with load resistance of 250Vac
mechanical life: 2000 operations
Insulation resistance: 1000Mohm under 500V
Dielectric strength: between contacts: 1000Veff between contacts and ground: 2000Veff 50Hz
between contacts: 1000Veff
between contacts and ground: 2000Veff 50Hz
Operating temperature: -40°C to +85°C
breaking capacity: silver-plated contacts 2A / 250V
min. Load: silver-plated contacts 100mA 10V
Initial contact resistance: Silver: <10mohm Gold: 50mohm
Silver: <10mohm
Gold: 50mohm
Pushbutton + switch type | Switch |
Item number | 5842543 |
Manufacturer | Velleman |
Category | Buttons + Switches |
Manufacturer no. | H251B |
Release date | 12.7.2016 |
Pushbutton + switch type | Switch |
rank | Slide switches |
Country of origin | Taiwan |
CO₂-Emission | |
Climate contribution |
Length | 1.50 cm |
Width | 1.50 cm |
Height | 0.80 cm |
Weight | 1 g |
