Ubiquiti UISP-S

Ubiquiti UISP-S - UISP Switch

The UISP Switch is a fanless Layer 2 PoE switch featuring 8 GbE RJ45 ports and 1 G SFP port for an additional fiber uplink option. It is ideally suited for Wireless ISP (WISP) installations and offers a cost-effective solution for WISPs looking to provide their customers with fast and affordable Gigabit wireless speeds. With a total power output of 110 W, the UISP Switch supplies sufficient power to each radio in your service network. For larger installations, it can be combined with the UISP console to create a cohesive routing and switching hub. The UISP Switch is managed through the UISP application, a centralized platform for monitoring and managing all UISP devices.

Mechanical

Dimensions: 210.4 x 95 x 29 mm
Weight: 610 g
Enclosure Material: Polycarbonate

Hardware

Non-blocking total throughput: 9 Gbps
Switching capacity: 18 Gbit/s
Forwarding rate: 13.392 Mpps
Network interface: 8x 10/100/1000 MbE RJ45 ports; 1x 1G SFP port
Management interface: Ethernet in-band; Bluetooth BLE
Power supply: External AC/DC adapter
Power supply: 27 V DC, 4.4 A power supply (included)
Supported voltage range: 24 - 28 V DC
Max. power consumption: 8 W (without PoE output)
ESD/EMP protection: Air: ±15 kV; Contact: ±8 kV
Operating temperature: -10°C to 50°C
Operating humidity: 5 to 95% non-condensing
Certifications: CE, FCC, IC

PoE

PoE interface: 8x 27 V passive PoE: 2-pair or 4-pair
Max. passive PoE wattage per port: 30 W/27 V DC
Passive PoE voltage range: 27 V DC

LEDs

System: Status
RJ45 data ports: PoE; Speed/Link/Activity
SFP data port: Connection/Activity.
