Product details
Short info: Ubiquiti airFiber 11 - Wireless bridge. Manufacturer: Ubiquiti. Product Art. No: AF-11. EAN/UPC: 0810010071620.
Product Description: Ubiquiti airFiber 11 - Wireless bridge. Device type: Wireless bridge. Form factor: External. Processor: 1 x INVICTUS 2 IC. Data link protocol: AirFiber. Frequency band: 11 GHz. Power channel bandwidth: 3.5/5/7/10/14/20/28/30/40/50/56 MHz. Latency: 200 µs.
Accessories included: PoE injector, pole mount, 2 plastic zip ties. Power over Ethernet (PoE) support: Passive PoE.
Dimensions (width x depth x height): 11.2 cm x 8.6 cm x 32.7 cm. Weight: 2.26 kg.
Detailed specifications:
General Information: Device type: Wireless bridge. Width: 11.2 cm. Depth: 8.6 cm. Height: 32.7 cm. Weight: 2.26 kg.
Processor / Memory / Storage capacity: Installed processors: 1 x INVICTUS 2 IC. Network form factor: External. Connection technology: Wireless. Data transmission rate: 1.2 Gbps. Line coding format: 64 QAM, 256 QAM, QPSK, 16 QAM, 1024 QAM, 4 QAM. Data link protocol: AirFiber.
Wi-Fi frequency band | Single band |
PoE Standard | Passive 24V PoE-in |
Operating modes | Bridge |
Area of application | Outdoor |
Number of RJ45/LAN ports | 2 |
Max. port speed | 1000 Mbit/s |
Item number | 17711667 |
Manufacturer | Ubiquiti |
Category | Access points |
Manufacturer no. | AF-11 |
Release date | 16.6.2021 |
Operating modes | Bridge |
Long range coverage | 300 km |
Number of RJ45/LAN ports | 2 |
Max. port speed | 1000 Mbit/s |
5 GHz transfer rate | 1000 Mbit/s |
Wi-Fi frequency band | Single band |
Wi-Fi encryption | WPA2-AES |
Area of application | Outdoor |
Installation place | Rod |
Power supply | PoE |
PoE Standard | Passive 24V PoE-in |
Power consumption | 36 W |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | 2 plastic cable ties, PoE injector, Rod mounting |
Length | 8.60 cm |
Width | 11.20 cm |
Height | 32.70 cm |
Weight | 2260 g |
