Supermicro Barebone IoT SuperServer SYS-E300-12D-10CN6P

Ratings
BrandMore from Supermicro
Currently out of stock
Free shipping starting at 50.–

Product details

The Barebone IoT SuperServer SYS-E300-12D-10CN6P from Super Micro Computer is a powerful server solution specifically designed for IoT applications. Equipped with an Intel Xeon D processor, this server offers high processing power and efficiency. With a compact form factor of 3U, the server is ideal for use in rack environments. The SYS-E300-12D-10CN6P supports up to 256 GB of DDR4 RAM with ECC, ensuring reliable data integrity. Its versatile connectivity options, including multiple LAN ports and SFP+ connections, allow for flexible network design and high data transfer rates of up to 25 Gbit/s. Additionally, the server provides space for various storage options, including M.2 connections and 2.5-inch drive bays, making it an adaptable solution for diverse requirements.

  • Supports up to 256 GB of DDR4 RAM with ECC for enhanced data integrity
  • Offers 4x LAN 1GbE and 2x LAN SFP28 25GbE for high network speeds
  • Integrated support for M.2 M/B/E-Key with Nano-SIM card slot
  • Equipped with a PCI-Express 4.0 x16 slot for expansion options
  • Compatible with a variety of RAID configurations for flexible data storage.

Key specifications

Processor family
Xeon D
Max. memory slots
4
Max. RAM
256 GB
Number of CPU sockets
1 x
Number of rack units
3 U
Item number
46922890

General information

Manufacturer
Supermicro
Category
Server barebones
Manufacturer no.
SYS-E300-12D-10CN6P
Release date
4.8.2023

Hardware form factor

Design
Rack Server
Number of rack units
3 U

Motherboard properties

Manufacturer
Supermicro
Chipset
Intel SoC
Number of CPU sockets
1 x
Processor family
Xeon D

Memory

Memory type
DDR4-RAM
Memory form factor
R-DIMM
Max. memory slots
4
Max. RAM
256 GB
RAM speed
2933 MHz
RAM error correction
ECC
RAM buffer
Registered

Data storage controller

Possible raid configuration
0, 1, 10, 5

Hard drive slots

Max. number of hard disks
1
Form factor
2.5"
Interface
M.2, SATA
Interface version
M.2 Key B, SATA II

External interfaces

USB ports
USB-A
Exact USB ports
USB-A 3.0 (2x)
Connectivity
RJ45

Internal interfaces

Internal connection options
M.2 (3x)
Expansion slot
PCI Express x16 (Gen 4) (1x)
PCI express version (max.)
4

Network

Network connections
RJ45 Gigabit Ethernet (4x)
Ethernet controller brand
Intel
Max. port speed
25000 Mbit/s

Video connections

Video connections
VGA (1x)

Optical drive properties

Optical drive type
No drive

Operating system

Operating system
No operating system

Mains supply properties

Number of power supply units
1 x
Max. number of power supply units
1

Origin

Country of origin
Germany

Voluntary climate contribution

CO₂-Emission
Climate contribution

Product dimensions

Length
225.80 mm
Width
264.80 mm
Weight
2.30 kg
