Shuttle Industry-grade Panel PC P21WL01-i5WA Intel® Core™ i5 (21.5 inch) Pixel Touchscreen DDR4-SDRAM SSD
Intel Core i5-8365UE, 8 GB, 250 GBProduct details
Industrial-grade panel PC with 21.5-inch display
The high-quality P21WL01 panel PC series features a robust aluminum housing with an IP65-compliant front, is powered by an Intel ULV processor, and has a Full HD display with projected capacitive 10-point multitouch functionality. Thanks to its passive cooling, the system operates almost silently, is maintenance-free, and is approved for 24/7 nonstop operation. The panel PC is available upon request with various Intel Core processors and additional features. This makes it ideally suited for rugged and public applications such as healthcare, hospitality, digital signage, POI, POS, kiosks, and industry.
PC type | All in One PC |
Processor family | Core i5 |
Operating System Version | Windows 10 IoT Enterprise |
Video connections | DVI, HDMI (1x) |
Exact USB ports | USB-A 3.2 Gen 1 (4x) |
Network connections | RJ45 (1x) |
Item number | 20849762 |
Manufacturer | Shuttle |
Category | PC |
Manufacturer no. | KPK-P21WL015WA1 |
Release date | 12.5.2022 |
Colour | Black, Blue |
Exact colour description | Black, Blue |
PC type | All in One PC |
Operating system | Windows |
Operating System Version | Windows 10 IoT Enterprise |
Operating system architecture | 64-bit |
Number of processors | 1 x |
Processor family | Core i5 |
Processor type | Intel Core i5-8365UE |
Clock frequency | 1.60 GHz |
Max. turbo clock rate | 4.10 GHz |
Max. TDP | 12.50 W |
Number of processor cores | 4 -Core |
Max. Turbo Clock frequency Performance Cores | 4.10 GHz |
Cache | 6 MB |
Memory | 8 GB |
Memory configuration | 1 x 8GB |
Max. supported memory | 64 GB |
Memory type | DDR4-RAM |
Set clock frequency | 1600 MHz |
Memory form factor | SO-DIMM |
Number of memory slots | 2 |
Data storage controller | Intel SoC |
Disk type | SSD |
Total capacity | 250 GB |
Form factor | M.2 |
SSD capacity | 250 GB |
Further data carrier type | SSD |
Storage capacity | 250 GB |
Chipset | Intel SoC |
Graphics hardware | Integrated graphics |
Graphics card model | UHD Graphics 620 |
Graphics chip (GPU) | Intel UHD Graphics |
Hardware interface | PCI Express Mini Card |
Max. Video resolution | 1920 x 1080 pixels |
Ethernet controller | Realtek RTL8821CE |
Max. port speed | 1000 Mbit/s |
Wireless transmission | Wi-Fi |
Bluetooth version | 4.2 |
Wi-Fi standard | Wi-Fi 5 / 802.11ac |
Audio channel | Stereo |
USB ports | USB-A |
Exact USB ports | USB-A 3.2 Gen 1 (4x) |
Video connections | DVI, HDMI (1x) |
Network connections | RJ45 (1x) |
Audio Connections | Headphones, Microphone |
Optical drive type | No drive |
Power supply | 90 W |
Display size (inches) | 21.50" |
Image resolution | 1920 x 1080 pixels |
Screen technology | LCD |
Display functions | Touch screen |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Length | 4.99 cm |
Width | 54.30 cm |
Height | 33.40 cm |
Weight | 7.60 kg |
Length | 67.30 cm |
Width | 48.30 cm |
Height | 15.30 cm |
Weight | 9.95 kg |
