Rittal NH fuse switch disconnectors

Rittal NH fuse switch-disconnector SV 9344.130
Manufacturer: Rittal
Designation: NH fuse switch-disconnector for mounting plates
Type: SV 9344.130
Design as main switch: No
Design as safety switch: No
Max. operating voltage Ue at AC: 690 V
Rated continuous current Iu: 250 A
Suitable for fuse-links: Other
Number of poles: 3
With fuse monitoring: No
Rated operational voltage Ue at AC: 690 V
Rated uninterrupted current Iu: 250 A
Suitable for fuse links: Other
Number of poles: 3
With fuse monitoring: No
Connection type main circuit: Screw connection
Suitable for floor mounting: No
Suitable for front mounting: Yes
Suitable for busbar mounting: Yes
Design of actuating element: Cover handle
Position of actuating element: Front
Motor drive optional: No
Motor drive integrated: No
Design as emergency stop device: No
Protection class (IP), front: IP20

Rittal NH fuse switch disconnector SV 9344.130: further details
SV NH fuse switch disconnector, size 1, 250 A, 400-690 V, 3-pole, screw M10, with electronic fuse monitoring, for mounting plate assembly, EAN: 4028177540620.
