Questions about Lian-Li O11 Dynamic Mini

ATX is feasible if you do without the radiators at the top and bottom... The case was clearly designed for mATX and ITX. If you want ATX, I would take the larger one. (The "Mini" in the name is a joke anyway. The part is almost as big as the gigantic 80-litre Lian Li O9 that I'm currently still using...)

The case can accommodate up to 9 fans. If the heatsink is included, the number of fans you can install depends on the type of heatsink used and the space available inside the case. In general, the heatsink takes up space that could otherwise be used for other fans.

The height of the case is 380 mm. This dimension allows a variety of components to be accommodated, while maintaining a compact design.

You cannot plug the headphone cable into the circular port next to the power button. The circular port is not mentioned among the available connections, which include USB 3.0, audio input/output and USB Type C.

ᝲ

The maximum number of fans you can install in the case, excluding the heatsink, is 9 fans. This includes the available positions on the lid, sides, bottom and rear of the case.

I'm not completely certain about this answer. The information I have does not fully address the question about the grid-like spaces being for cable management. However, the O11 Dynamic Mini is known for its dual-chamber design, which typically includes features for cable management, such as rubber grommets and multiple tie points to tidy up cables. For precise details about specific grid-like spaces, it might be helpful to consult the manufacturer's documentation or community forums.

The dimensions of the Lian Li O11 Dynamic Mini case are 420 mm in depth, 269.5 mm in width, and 380 mm in height.

Yes, the case supports mATX.

You need a small factor power supply. Search for SFX power supplies. They fit into the case. I have installed a Corsair SF750 in the Dynamic Mini.

Depends on the sizes of your components: Max. length graphics card: 395 mm Max. height CPU cooler: 170 mm The case allows you to add an additional 9 fans (without watercooling), which should be more than enough Airflow for your Components.

Hello, no, only an SFX or SFXL will fit in this enclosure. I would recommend the Corsair SF750 Platinum (750 W).

Corsair RM850x = ATX format SFX/ SFX-L fits into this enclosure as the manufacturer writes on its website https://lian-li.com/product/o11-dynamic-mini/ https://www.pcbuildersclub.com/basics/netzteil/#Format_und_Groesse

Unfortunately not, we don't sell this product at all anymore, I'm sorry.

Hello Severin, An extension frame for the mainboard was not included in my delivery. I have not been able to find the product otherwise. As a solution, I just screwed on the 6 screws and let the right side overlap. The expansion frame for a vertical GPU can be bought from Lian-Li itself via Digitec. You can find it under the name: Lian-Li O11D-1W-3 Mini Riser Card + PCI Slot Bezel - PCIe 3.0 Cost as of today: 69.50 CHF Hope I could help you further. Greetings

No, the enclosure is delivered without RGB or fan controller. PS: The Lian-Li UNI FAN SL in packs of 2 or 3 are supplied with an RGB+fan controller.

Ist halt die Frage was "normal" ist. ;-) Was passt findest du beim Hersteller https://lian-li.com/product/o11-dynamic-mini unter SPECIFICATIONS --> PSU
