Online USV Xanto 3000R: 3000VA/3000W
3000 VA, 3000 W, Online double converter UPS9 items in stock at third-party supplier
Product details
The Xanto 3000R is a state-of-the-art online double-conversion UPS specifically designed for use in server rooms and critical IT applications. With an output capacity of 3000 VA and a real power of 3000 W, this system provides reliable protection against power outages and data loss. The UPS is available in a flexible rack-tower design, allowing for easy integration into existing infrastructures. The Xanto 3000R ensures complete decoupling of consumers from the power supply network, enhancing the safety and stability of connected devices. With a typical backup time of up to 17 minutes at half load and 6 minutes at full load, along with a battery charging time of just 4 hours, this system is ideal for continuous operation. The UPS features seven AC outputs and supports various plug types, expanding connection options. Additionally, it offers comprehensive surge protection for fax machines, modems, and networks.
- Continuous operation technology for complete decoupling of consumers from the power supply network
- Scalable backup time with up to seven additional battery packs
- Noise level of a maximum of 50 dB for quiet operation
- Integrated USB and RS-232 ports for easy communication and monitoring
- Operating temperature range of 0 to 40 °C for versatile applications.
Electrical safety
Due to its high performance, this device requires a 16 Ampère socket (type 23). If no suitable wall socket is available, the conversion must be carried out by an authorised installer.Operating time at full load | 6 min |
Model | 19" rack |
Scope of application | Network cabinet, Server room |
Plug type | C20 |
Item number | 6521056 |
Manufacturer | Online USV |
Category | UPS |
Manufacturer no. | X3000R |
Release date | 4.9.2017 |
May include power adapter | Yes |
UPS type | Online double converter UPS |
Power output | 3000 W |
Output power capacity | 3000 VA |
Model | 19" rack |
Rack Unit | 2U |
shaft type | Sine wave |
UPS protection functions | Overvoltage protection |
Scope of application | Network cabinet, Server room |
Plug type | C20 |
Connections | USB 2.0 |
USB ports | USB-A |
Data ports | PS/2 (1x), RS-232 (1x) |
input voltage | 110 - 300 V |
output voltage | 240V |
Max. input current | 17.60 A |
Input frequency | 50 - 60 Hz |
Output frequency | 50 - 60 Hz |
Efficiency battery operation | 97 % |
Maximum operating temperature | 40 °C |
Operating temperature | 0 - 40 °C |
Max. noise level | 50 dB |
Protection type (IP code) | IP20 |
Battery category | Industry battery |
Battery | Rechargeable battery |
Battery type | Lead–acid battery |
Battery size | Device specific |
Number of cells | 6 x |
Battery weight per cell | 3230 g |
Voltage | 12 V |
Capacity | 9 Ah |
Charging time | 4 h |
Operating time at full load | 6 min |
Operating time at half load | 17 min |
CO₂-Emission | |
Climate contribution |
Scope of delivery | Input cable, Load cable, USB cable |
Items per sales unit | 1 x |
Height | 88 mm |
Weight | 27.50 kg |
Width | 438 mm |
Length | 632 mm |
Length | 76 cm |
Width | 60 cm |
Height | 20 cm |
Weight | 32.30 kg |
