Online USV ONLINE XANTO 6.000 Rack-Tower-Combination without battery Successor of XSRT6000

6000 VA, 4800 W, Online double converter UPS
Ratings
Delivered between Wed, 11.6. and Fri, 13.6.
Only 1 item in stock at supplier

Product details

Online UPS Systems XANTO 6000. Output capacity: 6000 VA, output power: 4800 W, input operating voltage (min): 110 V. AC connector types: Terminal, Connector: Terminal, Serial port: RS-232. Battery charging time: 4 hours. Form factor: Rackmount/tower, Color of product: Black, Rack capacity: 2U. UPS topology: Double conversion (online), Waveform: Sine, Noise level: 55 dB. The connection and commissioning of a UPS with more than 3.5 kVA must be clarified in advance with the local electricity provider. The connection must be carried out by an electrician.

Key specifications

Operating time at full load
6 min
Model
Desktop
Scope of application
Server room
Plug type
USB
Item number
10262366

General information

Manufacturer
Online USV
Category
UPS
Manufacturer no.
X6000
Release date
19.12.2018

UPS properties

UPS type
Online double converter UPS
Power output
4800 W
Output power capacity
6000 VA
Model
Desktop
Rack Unit
2U
shaft type
Sine wave

UPS functions

UPS protection functions
Overvoltage protection

Application range

Scope of application
Server room

Connector plug

Plug type
USB

Connections

Connections
RS-232, USB 2.0
USB ports
USB-C
Data ports
RS-232 (1x)

Mains supply properties

input voltage
110 - 300 V
output voltage
208 - 240 V
Max. input current
29 A
Input frequency
50 - 60 Hz
Output frequency
50 - 60 Hz
Efficiency battery operation
98 %

Operating conditions

Operating temperature
0 - 40 °C
Operating humidity
0 - 95%
Max. noise level
55 dB
Protection type (IP code)
IP21

Battery properties

Battery category
Device batteries
Battery
Battery
Battery type
Lead–acid battery
Battery size
Device specific
Number of cells
16 x
Voltage
240 V
Capacity
7 Ah
Charging time
4 h
Operating time at full load
6 min
Operating time at half load
17 min

Origin

Country of origin
China

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
Extension cable, Vertical frame
Items per sales unit
1 x

Product dimensions

Height
88 mm
Weight
17 kg
Width
438 mm
Length
610 mm

Package dimensions

Length
70 cm
Width
57 cm
Height
20 cm
Weight
15 kg

30-day right of return
24 Months Warranty (Bring-in)
