Murr Elektronik 7000-31261-0000000 Proportionalverstärker

Murrelektronik Proportional Amplifier 7000-31261-0000000

Manufacturer: Murrelektronik
Designation: Proportional Amplifier
Type: 7000-31261-0000000
Power Supply Type: Active
Rated Operating Frequency: 0 Hz
Rated Supply Voltage (DC): 24 V
Number of Input Ranges 0 V ... 10 V: 1
Number of Output Ranges 0 V ... 24 V: 1
Number of Channels: 1
Fault Signal Output: No
Intrinsic Safety according to EN 60947-5-6 NAMUR: No
Galvanic Isolation between Inputs: No
Galvanic Isolation between Input and Output: Yes
Galvanic Isolation between Outputs: No
Galvanic Isolation between Supply Voltage and all other Circuits: No
Height: 75 mm
Width: 22.5 mm
Depth: 102 mm
Operating Temperature: -20..60 °C
Device Design: Built-in Device
Electrical Connection Type: Screw Connection
Mounting Type: Snap Fastening
Mounting Rail
Protection Class (IP): IP20

The amplifier regulates the power supply to a proportional valve. This current is proportional to the setpoint at the amplifier's input. A voltage output of 10 V is available for setpoint specification. Zero point, current, rise and fall time (ramp). This product is intended exclusively for commercial use.
EAN: 4048879186810.
