Product details
Output voltage = 15V dc
Output current = 2.4A
Nominal power = 36W
Input voltage = 125 → 373 V dc, 88 → 264 V ac
Number of outputs = 1
Housing type = Closed
Length = 99mm
width = 82mm
depth = 36mm
Hum and interference voltage = 120mV ss
Load balancing = ±0.5%.
Mains balancing = ±0.5%.
Temperature min. = -25°C
Temperature max. = +70°C
Operating time = 249000h
EN60950, UL60950. UL approval; TÜV; CB. Power reduction by 2 % per °C above 50 °C for all types except: RD50, 65, 125, RS-75-3.3 Power reduction by 2 % per °C above 45 °C. RD85, RS-100-3.3, RS-150-3.3 and 5 Power reduction by 2 % per °C above 40 °C. 25 W to 150 W, universal input, single and double outputs. High efficiency, long life and high reliability Miniature version, high power density High operating temperature up to 70 °C Durable electrolytic capacitors up to 105 °C Easy installation - Screw terminals Adjustable output voltage for versions with single output: 10.8 - 13.2 V at 12 V and 22 - 27.6 V at 24 V To output 1 Adjustable output voltage for versions with dual output: -5 % to +10 % For dual outputs a minimum load applies, see output current (in data sheet). The total load must not exceed the rated output power. Harmonised to EN 61000-3-2 EMC to EN 55022 Class B short-circuit, overload and overvoltage protection.
