MeanWell LRS-75-12

EN60950-1, EN60335-1, EN61558-1 / -2-16, UL60950-1 and GB4943. Mean Well LRS switching power supply, 75 W output. The closed 75 W power supply units of the LRS-75 series are flat, very efficient products. The LRS-75 series was developed with a metallic grid and air convection for optimum heat dissipation for use in demanding applications. The LR-75 series has been developed for high efficiency and offers extremely low power consumption at no load. Installation in particularly challenging environments is possible thanks to 5 G vibration resistance. Features and benefits. Universal AC voltage input, with a 5-second overvoltage protection input, 300 V ac. Up to 91.5% efficiency with less than 0.3 W power consumption at no load. 5 G vibration resistance. Free air convection cooling. Typical applications:. Industrial automation and control systems. Mechanical and electrical appliances. Domestic appliances.

Output voltage = 12V dc
Output current = 6A
Rated power = 72W
Input voltage = 120 → 373 V dc, 85 → 264 V ac
Mounting type = Enclosure mounting
Enclosure type = Closed
Length = 99mm
Width = 97mm
Depth = 30mm
Hum and interference voltage = 120mV ss
Load regulation = ±0.5%
Mains regulation = ±0.5%
Temperature min. = -30°C
Temperature max. = +70°C
Operating time = 681.2kh
