Gigabyte Brix GB-BRI5-8250
Intel Core i5-8250UProduct details
The Gigabyte Brix GB-BRI5-8250 is an ultra-compact barebone PC designed for users seeking a powerful and space-saving solution. Featuring an Intel Core i5-8250U processor with four cores and a turbo clock speed of up to 3.4 GHz, this system delivers solid performance for various applications. The Brix is equipped with two SO-DIMM memory slots that support a maximum RAM capacity of 64 GB, making it ideal for multitasking and memory-intensive tasks. The integrated Intel UHD Graphics 620 provides appealing visual representation, while the variety of connectivity options, including HDMI, Mini DisplayPort, and multiple USB ports, ensures flexible connectivity. The Brix GB-BRI5-8250 is therefore an excellent choice for users who need a compact yet powerful PC.
- Ultra-compact design for space-saving applications
- Supports up to 64 GB DDR4 RAM for high performance
- Integrated Intel UHD Graphics 620 for enhanced graphics display
- Variety of connectivity options, including HDMI and Mini DisplayPort
- Built-in Wi-Fi (802.11ac) and Bluetooth 4.2 for wireless connectivity.
Graphics card model | UHD Graphics 620 |
Memory type | DDR4-RAM |
Video connections | HDMI (1x), Mini DisplayPort (1x) |
Network connections | RJ45 (1x) |
Internal connection options | M.2 (1x) |
USB ports | USB-A |
Number of processor cores | 4 -Core |
Item number | 10246644 |
Manufacturer | Gigabyte |
Category | Barebones |
Manufacturer no. | GB-BRI5-8250 |
Release date | 1.5.2018 |
Design | Small Form |
Processor type | Intel Core i5-8250U |
Clock frequency | 1.60 GHz |
Number of processors | 1x |
Number of processor cores | 4 -Core |
Number of threads | 8 |
Socket | BGA 1356 |
Max. turbo clock rate | 3.40 GHz |
Max. TDP | 25 W |
Processor properties | 64-bit architecture, Direct I/O Virtualization Technology (VT-d), Intel Virtualisation Technology (VT-x), Onboard processor |
Memory type | DDR4-RAM |
Memory form factor | SO-DIMM |
Number of pins | 260x |
Memory chip compatibility | DDR4-2400 |
Memory Slots available | 2 |
Max. memory slots | 2 |
Max. RAM | 32 GB |
Graphics card model | UHD Graphics 620 |
Hardware application range | Midrange, Workstations |
Max. connected monitors | 3x |
Internal connection options | M.2 (1x) |
USB ports | USB-A |
Exact USB ports | USB-A 3.0 (2x), USB-A 3.1 Gen 1 (1x) |
Network connections | RJ45 (1x) |
Max. port speed | 1000 Mbit/s |
Connectivity | RJ45 |
Wi-Fi standard | Wi-Fi 5 / 802.11ac |
Bluetooth version | 4.2 |
Video connections | HDMI (1x), Mini DisplayPort (1x) |
Audio outputs | 3.5mm jack (1x) |
Power | 65 W |
CO₂-Emission | |
Climate contribution |
Scope of delivery | VESA wall mounting adapter |
Width | 112.60 mm |
Length | 119.40 mm |
Height | 34.40 mm |
Length | 20.80 cm |
Width | 17 cm |
Height | 12.80 cm |
Weight | 1.45 kg |
