Gewiss Impulse switch

Gewiss Pulse Relay GWD6642
Manufacturer: Gewiss
Designation: Pulse Relay
Type: GWD6642
Function: mechanical
Switch Mounting Type: DIN rail
Width in Division Units: 1
Installation Depth: 72 mm
Number of Contacts as Normally Open: 1
Control Voltage 1: 12 V
Control Voltage Type 1: AC
Control Voltage Frequency 1: 50-60 Hz
Rated Switching Current: 16 A
Supply Voltage: 230 V
Supply Voltage Type: AC
Suitable for Manual Operation: yes

Gewiss Pulse Relay GWD6642: additional details
Pulse relay (remote switch) according to EN 60669-2-2 as a modular device. The maximum connection cross-sections for the contacts are fine wire 6 qmm / solid 10 qmm and for the coil connections 2.5 qmm. Can be combined with an auxiliary contact or a central control.
