Product details
Extended edge switching
The X590 Series can serve as the controlling aggregation switch within Extreme's innovative extended edge switching solution, simplifying the deployment and operation of connected edge switches. With both copper and fiber high-density 10Gb port options, the X590 Series can also flexibly accommodate top of rack and spine/leaf deployments.
ExtremeXOS intelligent L2/L3 switching
The ExtremeSwitching X590 Series supports sophisticated, intelligent Layer 2 switching, as well as Layer 3 IPv4/IPv6 routing, including policy-based switching and routing. The X590 Series simplifies network operation with the ExtremeXOS modular operating system, which is used across a wide range of ExtremeSwitching networking products.
High-performance 400Gb stacking
The X590 Series supports SummitStack-V400 400Gbps high-speed stacking using 2 100Gb ports. Up to 8 X590, X690 or X870 systems can be stacked using SummitStack-V400. Any of the supported 100Gb QSFP28 direct attach cables can be used for the stacking links.
Max. port speed | 10000 Mbit/s |
Network connections | SFP+ (48x) |
Switchtype | Rack Switch |
Management | Fully managed |
Item number | 12210534 |
Manufacturer | Extreme Networks |
Category | Network switches |
Manufacturer no. | 16790 |
Release date | 20.10.2019 |
Colour | Violet |
Exact colour description | Violet |
Switchtype | Rack Switch |
Rack Unit | 1U |
Number of ports | 24 Ports |
Management | Fully managed |
switching layer | Layer 2 |
Switching capacity | 880 Gbit/s |
Max. Number of VLANs | 4092 x |
MAC adress table size | 272000 |
Network connections | SFP+ (48x) |
Max. port speed | 10000 Mbit/s |
Max. port speed RJ45 | 1000 Mbit/s |
Max. Port speed | 10 Gbps |
Application range | Business |
Network operation | Power supply internal |
Power consumption | 770 W |
CO₂-Emission | |
Climate contribution |
Scope of delivery | Instruction manual |
Length | 48.80 cm |
Width | 44.10 cm |
Height | 4.30 cm |
