Brumberg LED converter

Brumberg Leuchten LED Converter 17643000

Manufacturer: Brumberg Leuchten
Designation: LED converter 350mA 18W phase dim
Type: 17643000
Design: Dynamic
Suitable for outdoor use: No
Dimming 0-10 V: No
Dimming 1-10 V: No
Dimming DALI: No
Dimming DSI: No
Dimming DMX: No
Dimming potentiometer (device-integrated): No
Dimming GPRS: No
Dimming LineSwitch: No
Dimming manufacturer-specific: No
Dimming mains voltage modulation: No
Dimming phase section: Yes
Dimming phase angle: No
Dimming programmable: No
Dimming RF: No
Dimming Sine Wave Reduction: No
Dimming Touch and Dim: No
Dimming Zigbee: No
Dimming with Push-button: No
Constant luminous flux control: No
Without dimming function: No

Housing: Plastic housing
Suitable for constant current: Yes
Suitable for constant voltage: No
Output voltage: 25..51 V
Output current: 350 mA
Output power: 8.75..18 W
Protection class (IP): IP20
Protection class: II
Length: 110 mm
Width: 52 mm
Height: 22 mm
Compatible with Apple HomeKit: No
Compatible with Google Assistant: No
Compatible with Amazon Alexa: No
IFTTT support available: No

This LED converter is phase section dimmable and is protected by fuse devices against overvoltage, short circuit, and thermal and electrical overload. The input and output terminals are suitable for cables with a cross-section of up to 1.5 mm². Material: Plastic. Protection class according to DIN EN 60529: IP20, protection class (EN 61140): II, voltage: 230V AC 50Hz, wattage: 18W, type of dimming: phase section.
