AsRock Box-V1000M

AMD Ryzen Embedded R1505G
Ratings
BrandMore from AsRock
Currently out of stock
Free shipping starting at 50.–

Product details

The ASRock 4X4 BOX-V1000M Barebone enables quiet computing in a very compact form factor. No matter the application, the 4X4 BOX-V1000M is powerful enough to handle everyday tasks. The barebone is equipped with an AMD Ryzen Embedded V-Series processor and an integrated AMD Radeon Vega 8 graphics unit. In addition to two DDR4-2400 SO-DIMM slots with ECC support, it features one HDMI and two DisplayPort connections. For communication, there are two RJ-45 ports (10/100/1000 MBit/s) and ac-Wi-Fi available.

Key specifications

Graphics card model
Radeon RX Vega 8
Memory type
DDR4-RAM
Video connections
DisplayPort (1x), HDMI (1x)
Network connections
RJ45 (2x)
Internal connection options
S-ATA III (1x)
USB ports
USB-A
Number of processor cores
4 -Core
Item number
13876096

General information

Manufacturer
AsRock
Category
Barebones
Manufacturer no.
90PXG690-P0EAY100
Release date
25.9.2020

Barebone properties

Design
Small Form

Processor

Processor type
AMD Ryzen Embedded R1505G
Clock frequency
2 GHz
Number of processors
4 x
Number of processor cores
4 -Core
Number of threads
8
Socket
Socket F
Max. turbo clock rate
3.60 GHz
Max. TDP
96 W

Memory

Memory type
DDR4-RAM
Memory form factor
SO-DIMM
Number of pins
260 x
Max. memory slots
2
Max. RAM
32 GB

Graphics card properties

Graphics card model
Radeon RX Vega 8
Max. connected monitors
3 x

Internal connections

Internal connection options
S-ATA III (1x)
"Number of 2.5"" drive slots"
1 x

External connections

USB ports
USB-A
Exact USB ports
USB-A 3.1 Gen 1 (3x)

Network

Network connections
RJ45 (2x)

Wireless transmission

Connectivity
Bluetooth
Wi-Fi standard
Wi-Fi 5 / 802.11ac
Bluetooth version
4.2

Video connections

Video connections
DisplayPort (1x), HDMI (1x)

Power supply properties

Power
96 W

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
VESA mounting kit, screw set, M.2 SSD heatsink

Product dimensions

Weight
1000 g
Width
110 mm
Length
118.50 mm
Height
67.30 mm

Package dimensions

Length
20.50 cm
Width
14 cm
Height
13.50 cm
Weight
1.75 kg
