Product details
Contact arrangement: SP
Switching sequence: On-Off
Rated contact current: 10 A @ 24 V dc
Mounting type: Front panel mounting
Connection type: Soldering, spade terminals
Actuator length: 13.5 mm
Actuator material: Polyamide
Contact resistance: 10 mΩ
Contact material: Silver-nickel alloy
All with contact resistance of 10 mΩ or less. For preloaded switches, "(ON)" refers to the momentary position. Toggle switches are standard, 15 A, with a flat insulated lever. Available in single and double pole configurations with a choice of flat insulated or traditional metal levers. Features a 12 mm mounting socket and 250 (1/4") terminals. Brass actuator and melamine/polyester housing with silver/nickel alloy contacts.
Pushbutton + switch type | Switch |
Colour | Black |
Item number | 9948312 |
Manufacturer | APEM |
Category | Buttons + Switches |
Manufacturer no. | 631NH/2 |
Release date | 22.10.2018 |
Sales rank in Category Buttons + Switches | 101 of 16722 |
External links |
Colour | Black |
Pushbutton + switch type | Switch |
LED colour | without LED |
rank | Toggle |
CO₂-Emission | |
Climate contribution |
Items per sales unit | 1 Piece |
Length | 5.50 cm |
Width | 0.80 cm |
Height | 3 cm |
Weight | 16 g |
